Traxxas 103076-4-RED - Spartan-SR Self-Righting Brushless - RÖD
Extreme Full-Throttle Fun with Self-Righting SecuritySpartan SR is built for speed and performance. Pull the trigger and Spartan SR immediately jumps on plane and rips across the water to its heart-pounding 50+ mph top speed! There’s nothing else like it and nothing holding you back. If a wave pitches the wrong direction, self righting is on board and within seconds, Spartan SR is back to extreme, full-throttle fun.
Spartan SR Features:
- NEW Self-Righting Flood Chamber
- NEW Watertight Clipless Hatch
- NEW Centralized Battery Positioning
- NEW Heavy-duty Flex Shaft
- NEW Removable Electronics Tray
- 80+kph VXL-6s™ Marine power system
- High performance 36˝ deep-V hull
- Waterproof electronics
- TQi™ 2.4GHz radio with TSM®
- Anodized aluminum rudder and drive strut
- Stainless steel turn fins, trim tabs and hex hardware
- Efficient water cooling system
- Quick-release motor collet
Self-Righting Security
Self righting is more than a convenience feature, it’s an all-access pass to exploit the full potential of Spartan SR’s 80+kph fury. Practice back flips and execute perfect 360° spins, all with the confidence-inspiring security of self righting.
HOW It WORKS
If Spartan SR flips over, the flood chamber immediately begins filling with water until the boat rights itself. A molded foam insert in the bow provides excess buoyancy. Once Spartan has righted itself, hit the throttle to drive away and the water in the flood chamber instantly exits the rear of the boat. The entire process takes only seconds and Spartan is back in the action.
UPDATED DEEP-V HULL
Spartan SR’s narrow deep-V hull provides extra stability to cut through chop and catch air over breakers. The hull rides higher on plane, giving Spartan SR a lighter, more responsive feel in the water.
- Razor-sharp handling, no-lift turns, and superior high-speed stability
- New low-CG electronics layout drastically improves handling
- Weight is concentrated inboard along the centerline
- Sharp, intuitive steering feel
- Tight turning radius – in both directions!
80 KPH Top-Speed
Grab a fistful of throttle and Spartan SR’s VXL-6s™ Marine power system transforms 22+ volts of LiPo power into furious acceleration. The high-performance prop digs in, getting the boat on plane quickly and efficiently as it slices through the water at speeds of 80 kph and beyond.
REMOVABLE ELECTRONICS TRAY
- Provides a rigid mounting structure
- Lifts out as a single piece
- Simplifies maintenance
CENTRAL BATTERY POSITIONING
- Lowers CG for improved stability
- Generous 218 mm length
- Adjustable battery position changes how high the bow rides in the water (trim)
HEAVY DUTY FLEX SHAFT WITH HIGH PERFORMANCE PROP
- Heavy duty flex shaft is 25% larger for improved power handling
- Shorter distance between motor and prop for greater efficiency
- Consistent prop surface finish resists nicks and bending
- Prop is inexpensive to replace with no performance loss to metal props
TQi 2.4GHZ RADIO SYSTEM WITH TSM®
The high-output Traxxas TQi 2.4 GHz radio system delivers superior range, precision, and control and it’s Traxxas LinkTM enabled for optional telemetry.
- TSM enhances Spartan SR’s straight-line stability
- 30 model memory
- Programmable Multi-Function knob
- 5-channel micro receiver with fail-safe security
- Patented waterproof receiver box
FACTORY-APPLIED GRAPHICS
Spartan SR uses bright, colorful graphics for excellent visibility and the hottest look on the water. The graphics are printed directly on the hull to get Spartan SR out of the box and into the water with speed and style.
SEALED CLIPLESS HATCH
Spartan SR’s injection-molded hatch secures tightly to the foam seal to keep water out. Four low-profile, quarter-turn hatch nuts hold the hatch perfectly in place without the need for time-consuming thumbscrews. Use the included hatch nut tool or switch to the optional tool-free wingnuts.
Specs:
- Hull Type: Deep-V
- Hull Length: 927 mm
- Overall Length: 1037 mm
- Width: 243 mm
- Height: 183 mm
- Deadrise: 26 degrees
- Weight (no battery): 2.40 kg
- Speed Control: VXL-6s™ Marine electronic
- Motor (electric): Velineon® 540XL Marine brushless
- Cooling: Water-cooled jacket
- Hull Material: Vacuum-formed ABS
- Drive System: Direct drive 4.7 mm flex cable
- Prop: 42 mm 2-blade composite (59 mm pitch)
- Outdrive: Adjustable aluminum
- Steering Servo: 2056 waterproof
- Radio System: TQi™ 2.4 GHz (2-channel)
- Receiver: 6533 2.4 GHz TSM® 5-channel
- Svårighetsnivå: 2
- Battery Compartment: L218 x W70 mm
What’s In The Box:
- Spartan SR with VXL-6s Marine ESC and 1850 kV motor
- Quick Start Guide
- TQi 2.4 GHz radio system
- Boat stand
- Hatch nut tool
- Optional wingnuts
What You’ll Need:
- Batteries: Spartan SR requires dual 7-cell NiMH or dual 2s or 3s LiPo batteries
- Charger: Traxxas EZ-Peak® Dual 3s (2972) is recommended for easy and fast charging performance
- AA Alkaline Batteries: Four AA alkaline batteries for the transmitter
